| Customization: | Available |
|---|---|
| Certification: | ISO9001, FCC, RoHS, CE |
| Height: | Low Attitude |
| Quantity: | |
|---|---|
| Package | Carton Size | 900×1140×1090mm |
| Carton Weight(Gross Weight) | 85kg | |
| Aircraft Frame | Motor | 6 |
| Symmetrical Motor | 1860mm | |
| Spreaded Size(No Rotors) | 2000×2000×790mm | |
| Folded Size | 1200×1100×790mm | |
| Motor | Model | D9 |
| KV | 110kv | |
| Max Pulling Force | 21.5kg | |
| Max Power | 3600W | |
| Electrical Control | Max Current | 120A |
| Voltage | 44.4V(standard) | |
| Pulse Width | 1100us-1940us | |
| Foldable Propellers | Material | Polymer+Carbon Fiber |
| Diameter | 3295mm | |
| Screw Pitch | 78mm | |
| Spraying System | Tank Volume | 25L |
| Nozzle Model | XR110015VS | |
| Nozzle Quantity | 6 | |
| Spraying Flow Rate(Max) | 4L/min | |
| Spraying Width(Depending On Height) | 4-6m | |
| Atomized Particle | 130-250um | |
| Max Pressure of Pump | 0.8Mpa | |
| Max Power of Pump | 35W | |
| Flight Parameters | Whole Unit Weight(Without Battery) | 18.25kg |
| Max Take off Weight | 63kg | |
| Hovering Accuracy | Horizontal:±0.8m Vertical:0.5m | |
| Fullload Hovering Time | 10min | |
| No load Hovering Time | 24min | |
| Max Flight Speed | 10m/s | |
| Recommended Flight Temperature | 0-50℃ | |
| Efficiency | 25acres/h | |
| Remote Controller | Frequency | 2.400-2.483 GHz |
| Effective Distance(Without Interference) | 3km | |
| Rated Voltage | 3.7V | |
| Battery Capacity | 10000mAh | |
| Weight | 1.05kg | |
| Supported Language | Chinese / English / Others | |
| Battery Charger PC2500 | Input | 100-240V 50/60HZ |
| Output | 2500W/1200W | |
| Channels | Multi-Channel | |
| Size | 294×139×282mm | |
| Weight | 5.6Kg | |
| Battery | Voltage | 51.8V(Standard) |
| Volume | 14S 22000mAh | |
| Size | 174*117*238mm | |
| Weight | 7.4kg/pc |
